Dimensions and specifications
- Model: HY3PR
- Size: 53.0 * 52.4 * 15.0 (mm)
- Input voltage: 24.0 V DC
- Atomization power (atomization amount): 12.0 W (≤ 35mL/H)
- Atomization frequency: 2.4MHz
Product Description
- 1、 Universal economy model, suitable for various ultrasonic atomization products
- 2、 Equipped with atomized sheet dry burning protection
- 3、 The CN3 socket has a+5V output, which can provide power to the external control board
- 4、 This atomizing motherboard has been widely used in the market with stable functionality
Socket and Pin Position Description
- CN2: Power input (24V DC)
- CN1: Fan output (12V/24V DC)
- Y1: Atomization output
- CN3: Connect the control board
- GND -- Connect the negative terminal of the keypad
- 5V - Supply power to the keypad+5V
- IR - Remote Control Signal Transmission
- Other foot positions - signal transmission
