Dimensions and specifications
  • Model: W2236
  • Size: 41.0 * 26.0 * 21.0 (mm)
  • Input voltage: 5.0 V DC
  • Atomization power: 5 W
  • Atomization frequency: 3.0MHz
Product Description
  • 1、 Mini charging model, suitable for various ultrasonic atomization aromatherapy products
  • 2、 The product comes with an automatic sensing setting that automatically stops aromatherapy when people walk
  • 3、 Having dual power supply from external power source and battery, it has a wider range of applications and is more portable
  • 4、 This aromatherapy motherboard has been widely used in the market and meets safety regulations and EMC certification standards
Socket and Pin Position Description
  • CN2: Charging power input (5V DC)
  • CN3: Connect rechargeable battery (4.2V DC)
  • CN1: Atomization output
